Hikvision DS-2CD2043G2-I | 4MP AcuSense POE Infrared Bullet Camera with H.265+

The Hikvision DS-2CD2043G2-I is a 4MP AcuSense POE infrared network HD bullet camera designed to provide high-quality surveillance with intelligent features. With advanced AcuSense technology, it classifies human and vehicle targets for precise alerts, reducing false alarms.

Key Features:

• 4MP Resolution: Captures sharp and detailed images at 2688 × 1520 resolution.
• AcuSense Technology: Intelligent classification of human and vehicle targets for accurate event detection.
• Efficient Video Compression: H.265+ compression minimizes storage and bandwidth requirements.
• Wide Dynamic Range (WDR): 120 dB WDR for clear images in high-contrast lighting conditions.
• Infrared Night Vision: IR range of up to 40 meters ensures effective monitoring in complete darkness.

DS-2CD2043G2-I Camera:

General Features:

• Image Sensor: 1/3″ Progressive Scan CMOS
• Resolution: 4 MP (2688 × 1520)
• Illumination:
  • Color: 0.005 Lux @ (F1.6, AGC ON)
  • 0 Lux with IR on
• Shutter Speed: 1/3 s to 1/100,000 s
• Day & Night: IR cut filter for day/night functionality
• Wide Dynamic Range (WDR): 120 dB for clear imaging under varying light conditions
• Angle Adjustment:
  • Pan: 0° to 360°
  • Tilt: 0° to 90°
  • Rotate: 0° to 360°

Lens:

• Lens Options: Fixed focal lengths: 2.8 mm, 4 mm, and 6 mm
• Field of View (FOV):
  • 2.8 mm: Horizontal 103°, Vertical 55°, Diagonal 122°
  • 4 mm: Horizontal 84°, Vertical 45°, Diagonal 100°
  • 6 mm: Horizontal 52°, Vertical 28°, Diagonal 61°
• Aperture: F1.6
• Lens Mount: M12
• DORI (Detection, Observation, Recognition, Identification):
  • 2.8 mm: D: 67 m, O: 26 m, R: 13 m, I: 6 m
  • 4 mm: D: 80 m, O: 31 m, R: 16 m, I: 8 m
  • 6 mm: D: 120 m, O: 47 m, R: 24 m, I: 12 m

Illuminator:

• Supplement Light Range: Up to 40 m
• Supplement Light Type: IR (850 nm)
• Smart Supplement Light: Yes

Video & Compression:

• Main Stream (Resolution & Frame Rate):
  • 50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
  • 60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
• Sub-Stream:
  • 50 Hz: 25 fps (640 × 480, 640 × 360)
  • 60 Hz: 30 fps (640 × 480, 640 × 360)
• Third Stream:
  • 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
  • 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
• Compression:
  • Main Stream: H.265+/H.265/H.264+/H.264
  • Sub-Stream: H.265/H.264/MJPEG
  • Third Stream: H.265/H.264
• Video Bit Rate: 32 Kbps to 8 Mbps
• Bit Rate Control: CBR/VBR
• Scalable Video Coding (SVC): Supports H.264 and H.265

Network:

• Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, PPPoE
• Simultaneous Live View: Up to 6 channels
• Storage: MicroSD/SDHC/SDXC card (up to 256 GB), NAS, and ANR support
• Security Features: Password protection, IP filtering, HTTPS encryption, TLS 1.1/1.2, and more
• APIs: ONVIF (Profiles S and G), ISAPI, SDK

Image;

• Settings: Rotate, mirror, privacy mask, brightness, contrast, saturation, and sharpness adjustments
• Image Enhancement: 3D DNR, BLC, HLC
• Day/Night Switching: Auto, Day, Night, Schedule

Interface:

• Ethernet Interface: 1 RJ45 10M/100M self-adaptive port
• On-Board Storage: Supports microSD cards up to 256 GB
• Built-In Microphone: Yes

Smart Features:

• Basic Events: Motion detection, video tampering alarm
• Smart Events:
  • Line crossing detection
  • Intrusion detection
  • Face detection
  • Human and vehicle target classification using deep learning

General Specifications:

• Power Supply:
  • 12 VDC ± 25%, max. 6 W
  • PoE: 802.3af, Class 3, max. 7 W
• Operating Conditions: -30 °C to 60 °C (-22 °F to 140 °F), 95% humidity or less
• Protection: IP67-rated for water and dust resistance
• Dimensions: Ø70 × 161.7 mm
• Weight: Approx. 490 g (camera only), 724 g (with packaging)

Certifications:

• EMC: FCC, CE-EMC, RCM, IC, KC
• Safety: UL, CB, CE-LVD, BIS
• Environmental: CE-RoHS, WEEE, Reach

This camera is ideal for outdoor security applications, offering robust protection, advanced features, and high-quality imaging. Let me know if you'd like additional insights or recommendations!
